Plate heat exchanger

Maximum power of heat exchanger: 1000kW
Nominal power: 150-250kW
Number of discs: 40
Connection: 2" external thread
Nominal flow: 35 m³/h
Heat exchange surface: 3.80 m²
Operating pressure: 30 bar
Test pressure: 45-60 bar
Min. temperature: -190°C
Max. temperature: +225°C
Weight: 21 kg
Plate material: stainless steel 304 and 316
Plate thickness: 0.4 mm
Solder material: 99.9% Cu

DIMENSIONS:

Length (A): 616 mm
Width (B): 191 mm< /span>
Depth (F): 103 mm
Distance (C) : 519 mm
Distance (D): 92 mm

Operation tips:
⋅It is recommended to install the heat exchanger vertically
⋅The sides must be connected in countercurrent
⋅Periodic cleaning must be carried out on a heat exchanger

More information:

Plate heat exchanger

1000kW heat exchanger
40 plate stainless design
< span style="color: #000000;">Features:

heat exchanger made of 316 L stainless steel, soldered with 99.9% Cu copper
heating power between 150 and 250 kW, depending on the flow temperature.
connections 2"
permitted operating pressure up to 30 bar
test pressure 45-60 bar
maximum operating temperature up to +230°C
flow rate up to 35 m³/h

The Ba-95-40 heat exchanger is the second smallest heat exchanger of the Ba-95 series, with a 2" connector. Its surface is 3.80 m² and 40 If you need a heat exchanger with a larger surface or more plates, you can choose the Ba-95-50 or our largest series, the Ba-115 models.

Plate heat exchanger 40 plates 1000kW with 2" external connection Ba-95-40
